Solar Connector DC1000/1500V

Solar Connector DC1000/1500V

• IP67 Waterproof

• Simple on-site processing

• PPO high strength material

• High quality waterproof ring

• High current carrying capacity

• Insulation material to prevent electric shoock

• Mating safety provided bykeyed housings





ELECTRICAL TECHNICAL REFERENCE

Rated current 30A (2.5-6mm²) 30A (2.5-6mm²) 35A 35A
Rated voltage 1000V  DC
Test voltage 6000V(50Hz,1min)
Overoltage categor/Pollution degree CATⅢ/2
Contact resistance of plug connectors 1mΩ 1mΩ ≤5mΩ ≤5mΩ
Contact material Copper,Ag plated
Insulation material PPO PPO PPO/PC PPO/PC
Degree of protection IP2*/IP67
Plame class UL94-VO
Safety class Ⅱ
Suitable cable OD4.5-8.5(2.5-6.0mm²) 2.5-6.0mm² 2.5mm²~6mm²/
14AWG~10AWG
2.5mm²~6mm²/
14AWG~10AWG
Insertion force/Withdrawal force ≤50N/≥50N ≤50N/≥50N ≤50N ≤50N
Connecting System Cromp connection
Temperature range -40℃~+125℃ -40℃~+125℃ -40℃~+85℃ -40℃~+85℃
