How to reduce DC Isolating Switch failure frequency?
To fundamentally reduce the failure rate of DC isolating switch, you need a three-pronged strategy: selecting arc-resistant, certified components, such as Suntree's specialized models;
• 1~10 strings available app remote control
• up to 40a
• shutdown feedback signal
• up to 1500v auto shutdown exceeding 70 ℃
• ce certification
• 10000 mechanical life cycles
• ip65 protection & anti uv
• lsolator with CE,CB,TUV,SAA
| Model | S-ISOH-40-3 | S-ISOH-40-4 |
| MAIN LOOP PARAMETERS | ||
| Number of string | 3 | 4 |
| Max DC voltage | 1500Vac | |
| Max DC current | 40A | |
| Parameters | 1500V26A, 1000V40A,600V40A | |
| DC connector | MC4 | |
| CONTROL LOOP PARAMETERS | ||
| Power supply type | AC single phase | |
| Nominal voltage | 230Vac | |
| Operating voltage | 100-270Vac | |
| Nominal frequency | 50Hz | |
| Operating frequency | 47-53Hz | |
| Nominal Curren | 30mA | |
| Max current | 300mA | |
| AC connector | Plug-in | |
| PRODUCT PARAMETERS | ||
| Protection degree | IP65 | |
| Protection level | Class Ⅱ | |
| Certification | CE | |
| Switch according to | EN 60947-3 | |
| Number of operations | >10000 | |
| N.of operations under load | >1500 | |
| Operating temperature | -20℃ ~70℃ | |
| Temperature sensor trigger | 70℃ | |
| Warranty | 5 years | |
| Dimensions(L*W*H) | 300*280*115 | 350*280*115 |
| Weight | 3440g | 3950g |
