• Standard: IS0 8820-1, IS0 8820-8, JASO D622
• Rated voltage: DC500V
• Rated current: 100A, 125A, 150A, 175A, 200A, 250A
• Breaking capacity: 20kA
• Protection object: Provide safer and more reliable protection against overload and short-circuit current faults of electric vehicle lithium battery pack, Super-capacitor circuit , charging circuit, DC-DC converter and other devices.
• Applicable environment: Temperature from -35℃ to 85℃, humidity ≤90%.
• Material description: 95 alumina high strength ceramics and imported material fuse piece.
• Structure process: copper metal is riveted after welding process; The internal quartz sand is processed by solidification to prevent products from falling off in dynamic working conditions and prevent arc spraying which is caused by line faults.
| Product model | Rated current (A) | 1²t (A²s) | Breaking capacity | Power consumption (w) 0.5In |
Mounting bolts/torque | |
| Pre-arc | Fusing | |||||
| EV28J500-100A | 100 | 1050 | 3620 | 20KA time constant (L/R): 2ms ± 0.5ms |
3.20 | Mounting bolt M8, recommended mounting torque 12Nem |
| EV28J500-125A | 125 | 2200 | 7400 | 4.00 | ||
| EV28J500-150A | 150 | 3390 | 10200 | 4.90 | ||
| EV28J500-175A | 175 | 3840 | 11050 | 5.70 | ||
| EV28J500-200A | 200 | 4300 | 12800 | 6.80 | ||
| EV28J500-250A | 250 | 5400 | 15020 | 7.50 | ||
