SCB8-63H AC Circuit Breakers 6-63A

SCB8-63H AC Circuit Breakers 6-63A

• Small volume and large current,saving installation space.The rated current 63A miniature circuit breaker is only 18mm wide, saving 30% space.

•  Strong environmental adaptability and reliable operation in extreme environment.

• -5℃-40 ℃ ambient temperature application range,to meet the application needs of various occasions.

• Lighter operation.63A product has lighter operation force and is easy to operate.

• Contact indication window with clear position.The whole series of contact positions are visualized to avoid misoperation and more reliable use.

• It accordance with IEC60898-1,GB/T109631 standard.


ELECTRICAL TECHNICAL REFERENCE

Type Rated current (A) Pole(P) Rated voltage(V) Segmental force(A) Instantaneous trip type Instantaneous protection current range
SCB8-65H 6,10,16,20,25,
32,40,50,63
1.2.3.4 1P
2P
AC230/400 10000 B 3In
C 5In
D 10In
3P
4P
AC400
B 3In
C 5In
D 10In
