AC Energy Storage MCB SCB8T-80H

AC Energy Storage MCB SCB8T-80H

• Themosetting material shell, high stability of Mechanical property and size, Excellent corrosion resistance, and Heat resistance and arc resistance

• Beautiful appearance, exquisite results, quick tripping, din rail mounting

• Breaking capacity up to 10000A

• Optimal design for contact system and trip mechanism

• Special arc-extinguishing design, More perfect

• High reliability and long use life

ELECTRICAL TECHNICAL REFERENCE

Type SCB8T-80H
Poles 1P12P/3P/4P
Rated current 6-10-16-20-25-32-40-50-63-804
Rated voltage 230V/400V
Characteristic capacity 6KA/10KA
Electrical life 6000times
Mechanical life 20000times
Curve B,C,D
Certificate TUV,CE,IEC,GB
Standards IEC-60898.1
Connection terminal Screw terminal/Pillar terminal with calmp
Connection capacity Rigid conductor up to 25mm2
Fastening torque 2.0Nm
Installation On symmetrical DIN rail 35mm/Panel mounting
