AC Energy Storage MCB SCB8-63

AC Energy Storage MCB SCB8-63

• Small volume and large current,saving installation space.The rated current 63A miniature circuit breaker isonly 18mm wide, saving 30% space.

• Strong environmental adaptability and reliableoperation in extreme environment. 5℃-40 ℃ ambient temperature application range,to meetthe application needs of various occasions.

• More reliable performance.Temperature rise ≤55K, breaking capacity up to 6ka electricallife ≥4000 times.

• Lighter operation.63A product has lighter operation force and is easy to operate.

• Contact indication window with clear position.The whole series of contact positions are visualized to avoidmisoperation and more reliable use.

ELECTRICAL TECHNICAL REFERENCE

Product Model SCB8-63
Pole(P) 1P、2P 3P、4P
Rated current (A) 6、10、16、20、25、32、40、50、63A
Rated voltage (V) AC230/240 AC400
Segmental force(A) 6000
Instantaneous trip type B、C、 D
Instantaneous protection current range 3In

WIRE CROSS-SECTIONALAREA

Rated current (A) 1、2、3、
4、5、6
10 16、20 25 40、50 63
Wire cross-sectionalarea mm² 1 1.5 2.5 4 6 16
Wiring Tightening Torque N. m Both the power supply end and the negative teaching end are 2.0-2.3
