• Current-limiting miniature circuit breaker with overload and short-circuit protection.
• Suitable for AC 50/60Hz systems: single-pole up to 230V, 2/3/4-pole up to 400V.
• Protects industrial and commercial lighting distribution systems.
• Allows infrequent circuit switching under normal conditions.
• Supports manual dual-power switching with optional interlock accessory.
• Ensures continuous power supply to the load.
| Model | SCB8-125MTS | |||||
| Number of poles | 1 | 2 | 3 | 3 | 4 | |
| With neutral wire | N | N | ||||
| Frequency Hz | 50 | |||||
| Rated voltage Ue(V) | 230 | 400 | ||||
| Rated current In(A) | 40, 50, 63, 80, 100, 125, | |||||
| Overcurrent instantaneous trip type | 10In±20% | |||||
| Rated short-circuit breaking capacity Icn(A) | SCB8-125 6000 SCB8-125H 10000 | |||||
