• Standard: IS0 8820-1, IS0 8820-8, JASO D622
• Rated voltage: DC200V
• Rated current: 200A, 250A, 300A, 350A, 400A
• Breaking capacity: 10kA
• Protection object: Provide safer and more reliable protection against overload and short-circuit current faults of electric vehicle lithium battery pack, Super-capacitor circuit, charging circuit, DC-DC converter and other devices.
• Applicable environment: Temperature from -35℃ to 85℃, humidity ≤90%.
• Material description: 95 alumina high strength ceramics and imported material fuse piece.
• Structure process: copper metal is riveted after welding process; The internal quartz sand is processed by solidification to prevent products from falling off in dynamic working conditions and prevent arc spraying which is caused by line faults.
| Product model | Rated current (A) | 1²t (A²s) | Breaking capacity | Power consumption (w) 0.5In |
Mounting bolts/torque | |
| Pre-arc | Fusing | |||||
| SEV35B200-200A | 200 | 5200 | 20500 | 10kA time constant (L/R): 2ms ± 0.5ms |
3.00 | Mounting bolt M8, recommended mounting torque 12N·m |
| SEV35B200-250A | 250 | 7000 | 20500 | 3.90 | ||
| SEV35B200-300A | 300 | 10000 | 40000 | 4.50 | ||
| SEV35B200-350A | 350 | 15000 | 60000 | 5.10 | ||
| SEV35B200 400A | 400 | 20000 | 82000 | 5.50 | ||
